NAVAL SHIP FLANGE PIPE P/N 810-4715319 FIG 2-A,ITEM NO. 23
NSN 4730014635641
| Name | Value |
| BOLT CIRCLE DIAMETER | 5.500 INCHES NOMINAL |
| FLANGE DIAMETER | 6.625 INCHES NOMINAL |
| THICKNESS | 0.500 INCHES NOMINAL |
| SOCKET DIAMETER | 3.543 INCHES NOMINAL |
| BORE DIAMETER | 3.310 INCHES NOMINAL |
| BOLT HOLE DIAMETER | 0.562 INCHES NOMINAL |
| FLANGE SECTION STYLE | PLAIN FACE, SOCKET BRAZING NECK W/O BRAZING RING |
| FACE SEATING SURFACE CONDITION | MACHINED |
| MATERIAL | COPPER ALLOY |
