AEROQUIP ADAPTER STRAIGHT TO HOSE P/N 4-411-16
THE MANUFACTURERS DATA MANUFACTURERS CODE 01276 DESIGN CONTROL REFERENCE 4-411-16
NSN 4730000701263
| Name | Value |
| NOMINAL THREAD SIZE | 1.312 INCHES 1ST END |
| SEAT ANGLE | 37.0 DEGREES 1ST END |
| CRITICALITY CODE JUSTIFICATION | ZZZY |
| NOMINAL INSIDE DIAMETER HOSE ACCOMMODATED | 0.875 INCHES 2ND END |
| NOMINAL OUTSIDE DIAMETER HOSE ACCOMMODATED | 1.234 INCHES 2ND END |
| NOMINAL OUTSIDE DIAMETER TUBE ACCOMMODATED | 1.000 INCHES 1ST END |
| NOMINAL OVERALL LENGTH | 2.800 INCHES |
| MATERIAL | NICKEL ALLOY OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-N-281,CL A FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| FURNISHED ITEMS AND QUANTITY | 1 SOCKET |
